SPECIFICATIONS

• Power Amplifier Rated output & THD (8 ohm)8 X 100 W (8 Ω/ohms, 20 Hz to 20 kHz, T.H.D. 0.05 %)
• Power Amplifier Rated output & THD (4ohm)8 X 125 W (4Ω/ohms, 1 kHz, T.H.D. 0.1%
• Frequency Response20 Hz to 20 kHz : ±1 dB
• Connected loudspeaker Impedance4 – 16 Ω/ohms

• Loudspeaker Binding Posts4-way binding posts
• Digital InputsTOSLINK (2)
• Analog InputsRCA L/R (4)
• PreoutsRCA L/R (4)
• Subwoofer OutRCA Mono (4) (selectable)

• Channel AssignmentsStereo (Default), Dual Mono
• Volume Limit80-100%
• Balance-15dB to +15dB
• Adjustable High Pass / Low Pass Filters40-250 Hz / 40-120 Hz
• EQBass, Treble -5dB to +5dB
• Sound ModesStereo, Direct, Virtual, Dialog Enhancer, Night Mode
• TV Sound GroupingYes

• DecodingDolby Digital, LPCM, DSD
• Stereo PCM / Multi-channel PCMYes / Yes
• Stereo File Formats (HEOS network share or USB)WMA: up to and including 192 kbps, AAC & MP3: up to and including 320 kbps, WAV, ALAC, FLAC: up to and including 24-bit/192kHz, DSD: 2.8 MHz, 5.6MHz

• Bluetooth ReceiveN/A
• Bluetooth TrasmitN/A
• AirPlayAirPlay 2
• SpotifySpotify Connect

• Music Services Supported ((HEOS®, subject to change and local availability)Pandora, Spotify, TuneIn, SiriusXM, Amazon Music, Tidal, Tidal HiRes, iHeartRadio, Deezer, Deezer HiFi, Mood:Mix, Sony Hi-Res, AWA, QPlay, SoundCloud.
• Music stored on mobile deviceYes (iOS, Android or Kindle Fire)
• NAS (Network Attached Storage)Network share
• USB Storage Device PlaybackYes (4) (FAT32, NTFS formatted drives)

• Wired ConnectivityEthernet (2)
• Wireless ConnectivityN/A
• IR InputN/A
• IR LearningN/A
• Control System Compatibility via TCP/IPCreston, Control4, AMX
• HEOS® AppiOS, Android, Kindle Fire
• Trigger Output DC 12VYes (4)

• Product ColorBlack
• User InterfaceReset button, Front power button, Rear power switch
• Dimensions (W x D x H) Inches17.4 x 16.34 x 4.17
• Dimensions (W x D x H) mm442 x 415 x 106
• Weight (lbs)18
• Weight (kg)8
