Specifications
Amplifier
|
Total Amplifier Power (FTC)
|
310 W (FTC Power Output Rating) |
|---|---|
|
Total Amplifier Power (Peak)
|
745 W (This rating was not tested under the FTC standard) |
|
Total Amplifier Power (Peak, Raw Amplifier Power)
|
1160 W (This rating was not tested under the FTC standard) |
|
Amplifier Toplogy
|
Marantz Rise GaN FET |
Loudspeaker Array
|
Bass
|
1×6.5″ Marantz Gravity |
|---|---|
|
Wideband
|
3×2″ |
|
High Frequency
|
2×1″ |
Performance
|
Frequency Response
|
30Hz to 20kHz (+/-3dB), 22Hz (-10dB) |
|---|---|
|
Maximum SPL
|
104dB (1M) |
|
Peak SPL
|
114.5dB (1M) |
Audio Connectivity
|
Analog
|
1 pr. RCA L/R |
|---|---|
|
Digital
|
1 ea. TOSLINK Optical |
|
USB
|
1 ea. USB-C (Mass Storage) |
|
HDMI
|
1 ea. eARC / ARC |
Audio Format Support
|
Decoding
|
Dolby Atmos, Dolby TrueHD, DSD Dolby Digital+, Dolby Digital, LPCM |
|---|---|
|
Max PCM Sample Rate / Bit Depth –Stereo
|
192kHz / 24 bit |
|
Multi-Channel
|
192kHz / 24 bit (7.1 Channel) |
|
Max DSD Data Rate
|
5.6 MHz (DSD ×2) |
|
Stereo File Formats (HEOS network share or USB)
|
WMA: up to and including 192 kbps |
|
AAC & MP3
|
up to and including 320 kbps |
|
WAV, ALAC, FLAC
|
up to and including 24-bit/192kHz |
|
DSD
|
2.8 MHz, 5.6MHz |
Streaming Technologies
|
Bluetooth
|
BT 5.4 |
|---|---|
|
AirPlayAirPlay 2
|
|
|
SpotifySpotify Connect
|
Music Services and Sources
|
Music Services Supported (HEOS, subject to change and local availability)
|
Pandora, Spotify, TuneIn, SiriusXM, Amazon Music, TIDAL, iHeartRadio, Deezer, Deezer HiFi, Mood:Mix, Sony Hi-Res, AWA, Play, SoundCloud. |
|---|---|
|
Music stored on mobile device
|
Yes (iOS, Android, or Kindle Fire) |
|
NAS (Network Attached Storage
|
Network share, UPnP |
|
USB Storage Device Playback
|
Yes (FAT32, NTFS formatted drives) |
Networking & Control
|
Wired Connectivity
|
Ethernet |
|---|---|
|
Wireless Connectivity
|
Dual band, 802.11 a/b/g/n/ac/ax |
|
Control System Compatibility via TCP/IP
|
Crestron, Control4, AMX |
|
HEOS App
|
iOS, Android, Kindle Fire |
General
|
Product Color
|
Moon Ray, Midnight Sky, Marantz Champagne |
|---|---|
|
Included
|
Certificate of Authenticity, QSG, Power Cable, HDMI Cable |
|
User Interface
|
Volume up/down, Play / Pause, Multi colored LED status indicator, Connect button (rear), Bluetooth button (rear) |
|
Dimensions (H × W × D) Inches
|
14.33 × 8.27 × 15.26 |
|
Dimensions (H × W × D) mm
|
364 × 210 × 387.5 |
|
Weight (lbs)
|
27.5 |
|
Weight (kg)
|
12.5 |
