| System Type | 2 way, downwards firing port, with BassTrax™ Tractrix diffuser |
| Recommended amplifier power (Watt RMS) | 20 – 280 |
| Peak power handling (Watt) | 560 |
| Continuous power handling (Watt RMS) | 140 |
| Sensitivity (2.83 Volt @ 1m) | 94dB |
| Nominal impedance | 8 Ohm |
| Frequency response (-6dB typical in room) | 28Hz- 26kHz |
| Drive unit complement | 1 x 250mm IsoFlare point source driver, multi-fibre bass / midrange cone, with 75mm titanium alloy dome compression tweeter, ferrite magnet system |
| Crossover frequency | 750Hz |
| Crossover type | Bi-wired passive low loss, 2nd order low pass, 2nd order high pass. Cryo-Lite treated. |
| System adjustments | High frequency energy (1.8kHz – 26kHz) +/- 3dB, Presence (2.5kHz – 5.0kHz) +/- 3dB |
| Dimensions – HxWxD | 918 x 450 x 381mm (36.1 x 17.7 x 15.0″) |
| Net Weight – Each | 45.2kg |
| Finishes | Walnut |
| Cabinet Construction | High density fibreboard, walnut veneered with extensive internal bracing |
| S-Trax Position (from cabinet front edge) | 106mm (4.2″) |
| SuperTrax Position (from cabinet front edge) | 82mm (3.2″) |
