System Type 2 way, downwards firing port, twin cavity, BassTrax Tractrix diffuser
Recommended amplifier power (Watt RMS) 30 – 200
Peak power handling (Watt) 400
Continuous power handling (Watt RMS) 100
Sensitivity (2.83 Volt @ 1m) 91dB
Nominal impedance 8 Ohm
Frequency response (-6dB typical in room) 30Hz – 34kHz
Drive unit complement 1 x 200mm IsoFlare point source driver, multi-fibre bass / midrange cone, FyneFlute surround with 25mm magnesium dome compression tweeter, ferrite magnet system. Cryo-Lite treated.
Crossover frequency 1.8kHz
Crossover type Bi-wired passive low loss, 2nd order low pass, 1st order high pass
System adjustments High frequency energy (1.8kHz – 34kHz) +/- 3dB, Presence (2.5kHz – 5.0kHz) +/- 3dB
Dimensions – HxWxD 873 x 380 x 300mm (34.4 x 15.0 x 11.8″)
Net Weight – Each 29.1kg
Finishes Walnut
Cabinet Construction High density fibreboard, walnut veneered with extensive internal bracing
S-Trax Position (from cabinet front edge) 74mm (2.9″)
SuperTrax Position (from cabinet front edge) 50mm (2.0″)
