PRODUCT SPECIFICATIONS
| System Type | 2 way, downwards firing port, with BassTrax Tractrix diffuser* |
| Recommended amplifier power (Watt RMS) | 30 – 180 |
| Peak power handling (Watt) | 360 |
| Continuous power handling (Watt RMS) | 90 |
| Sensitivity (2.83 Volt @ 1m) | 91dB |
| Nominal impedance | 8 Ohm |
| Frequency response (-6dB typical in room) | 33Hz – 34kHz |
| Drive unit complement | 1 x 200mm IsoFlare point source driver, multi-fibre bass / midrange cone, FyneFlute surround with 25mm magnesium dome compression tweeter, ferrite magnet system |
| Crossover frequency | 1.8kHz |
| Crossover type | Bi-wired passive low loss, 2nd order low pass, 1st order high pass. Deep Cryogenically Treated |
| System adjustments | Presence (2.5kHz – 5.0kHz) +/- 3dB |
| Dimensions – HxWxD | 470 x 280 x 441mm (18.5 x 11.0 x 17.4”) |
| Net Weight – Each | 15.2kg (33.5lbs) |
| Finishes | Piano Gloss Walnut |
| S-Trax Position (from cabinet front edge) | 69mm (2.7″) |
| SuperTrax Position (from cabinet front edge) | 45mm (1.8″) |
